CNC Machines

CNC Machines

CNC Wire Cut FZC Series Machine

CNC Wire Cut FZC Series Machine
  • CNC Wire Cut FZC Series Machine
Get Best Quote
Approx. Price: Rs 11.7 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

Minimum Order Quantity1 Unit
BrandFostex
Country of OriginMade in India
Wire Dia0.30 mm
Wire Speed12, 9, 7, 5, 2 m/sec
Max Cutting Angle+/-3 deg/80 mm (15, 30 and 60 deg is Optional)
Driving MotorStepper Motor / AC Servo Motor (Optional)
Guide Screw and TrackPrecision Ball Screw / Linear Guide Way
Tension SystemThree Stage (0/1/2) Tension Adjustable
Power Supply415 V / 50 Hz, 2.5 kW
Weight2600 kg
Size2050x1850x2000 mm

We are one of the leading exporters, traders and suppliers of CNC Wire Cut FZC Series Machine that is manufactured in compliance with the industry standards. These are widely acknowledged for their speedy operation, longer operational life and tough construction. We offer turret milling machines at reasonable rates for our esteemed customers.

Features:
  • Robust frame with "C" mast.With height adjustable diamond guider.
  • Four axes independent (X/Y/U/V) work, with Taiwan linear and ball screw.
  • Special Tensioning mechanism for molybdenum wire,
  • Taiwan LM guide and ball screw



Specifications:

TypeFZC7732FZC7740FZC7750FZC7763
Table Size mm440x620510x730630x880850x1200
Table Travel X/Y mm320x400400x500500x630630x800
Max Cut Thickness mm300300400400
Travel Size U/V mmNormal: 24x24 Large taper: D-60x60 E-130x130 T-240x240
Wire Dia mmMolybdenum wire 0.10-0.30
Wire Speed m/sec12,9,7,5,2
Max Cutting Angle+-3deg/80 mm (15deg, 30deg and 60deg is optional)
Process Accuracy mmMulti cut: 10x10x30 Square Less than 0.006; Single Cut Less than 0.012 Multi-cut Octagon Less than 0.009; Straightness Less than 0.006/50 mm
Roughness Ra.umMulti cut: Ra less than 1.0 Micro pulse power Ra less than 0.8 Single cut: Ra Less than 2.0
Driving MotorStepper motor / AC servo motor
Request
Callback


Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P,D/A
  • Port of Dispatch: ANY PORT OF INDIA
  • Production Capacity: 100 SETS
  • Delivery Time: 3-4 WEEKS.
Yes! I am Interested

CNC Wire Cut FDK Series Machine

CNC Wire Cut FDK Series Machine
  • CNC Wire Cut FDK Series Machine
  • CNC Wire Cut FDK Series Machine
Get Best Quote
Approx. Price: Rs 8.5 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

BrandFostex
Automatic GradeAutomatic
Model Name/NumberFDK-7740
PowerSingle Phase,220V/50Hz / Three Phase,415V/50Hz (2.0 kW)
Dimension1600x1300x1500 mm (LxWxH)
Net Weight1350 kg
Table Size780x540 mm
Table Travel500x400 mm
Max Z Axis Travel500 mm
Max Workpiece Weight500 kg
Max Cutting Angle6deg (15deg,30deg)
Position Accuracy0.015/300 mm
Repeatability0.01 mm
Wire Moving Speed11.5 m/sec
Cutting Speed120-140 mm2/min
Wire Dia0.12-0.25 mm

Features:
  • Lowest Running Cost
  • Reusable Malybdenum wire
  • Multi pass facility (optional)
  • It can make option of High speed and Medium speed
  • High accuracy and fine surface quality cab be while machining speed in high
  • Coolant oil is used as dieletric / Low cost soap gel can be used as cutting oil
  • Maximum cutting speed : 180mm2/min
  • Low cost
  • Low Maintenance
  • Function of taper processing
  • Functions of interpolation of straight line and circular arc
  • Automatic centre find, edge find operation and pulse at wire break
  • Function of memorizing when power was cut and auto-stop after processing
  • Auto lock after giving run command
  • Good rigidity, running placidly, strong function, convenient and reliable operation

Specifications:

Model FDK7720-S, FDK7720-M FDK7725-S, FDK7725-M FDK7732-S, FDK7732-M FDK7735-S, FDK7735-M FDK7740-S, FDK7740-M FDK7745-S, FDK7745-M FDK7740J-S, FDK7740J-M
Table Size mm 490x380 580x400 700x440 700x440 780x540 780x540 1000x540
Table Travel X/Y mm 250x200 320x250 400x320 450x350 500x400 550x450 630x400
Max. Z Axis travel mm 350 350 400 450 500 550 500
Max. Workpiece weight kg 200 300 400 400 500 500 550
Max. Cutting Angle 6deg 6deg 6deg, 15deg 6deg, 15deg 6deg, 15deg, 30deg 6deg, 15deg, 30deg 6deg, 15deg, 30deg
Position Accuracy mm 0.015/300
Repeatability mm 0.01
Request
Callback
Yes! I am Interested

ZNC Electric Spark Discharge Machine

ZNC Electric Spark Discharge Machine
  • ZNC Electric Spark Discharge Machine
Get Best Quote
Approx. Price: Rs 6.25 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

BrandFostex
Country of OriginMade in India
Workbench550x300
Work Slot750x420x280
Capacity of filter box200 ltr
Machine Weight1000 kg
Before and after the trip200

Details:

  • Maximum working current (>60A), maximum power consumption (<6KVA), maximum processing speed (>450mm/min)
  • Minimum electrode consumption less than 0.3% finest surface roughness Ra less than 0.3 M output voltage 90-260V
  • Taiwan's 17-inch famous LCD industrial computer imports dedicated circuit boards and world-renowned brand electronic components.

Machine Tools:
  • The structure of the machine is designed by computer analysis of tension, compression and reaction force, so as to ensure the mechanical precision forever.
  • The castings are cast with FC-35 resin sand. They are durable and have the same precision after natural wind and various treatments.
  • Machinery design uses computer aided design (CAD) to persist in processing the invariant structure of the machine body to ensure the processing accuracy.
  • The sliding track adopts V-shape and plane design. It slides lightly under heavy pressure and has excellent precision.
  • The working table surface is grinded by high-wave heat treatment, and the surface is not easy to wear.
  • Both X and Y axes adopt imported or equivalent double nut ball screw, which has light transmission and convenient use.
  • The spindle adopts linear sliding track, which ensures the precision and durability forever.
  • The trawler adopts imported Tiefron guide rail veneer.
Request
Callback


Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer),D/P,D/A
  • Port of Dispatch: ANY PORT OF INDIA
  • Production Capacity: 100 SETS
  • Delivery Time: READY STOCK OR 2-3 WEEKS
Yes! I am Interested

CNC Electric Spark Discharge Machine

CNC Electric Spark Discharge Machine
  • CNC Electric Spark Discharge Machine
  • CNC Electric Spark Discharge Machine
Get Best Quote
Approx. Price: Rs 21 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

Overall WeightApprox 2000 kg
Oil Tank Capacity470 L
BrandFostex
Power18 kVA
Usage/ApplicationIndustrial
FeaturesHand control box, Mirror surface processing
ModelFCNC- 430

Features:
  • New generation FUZZY intelligent parameter editing function, adaptive discharge machining control.
  • Multi-segment parameter setting and different segments can be switched over easily Adaptive discharge machining control
  • Quick speed lifting for spindle and the height can be changed
  • Spindle can be controlled by fixed point, and the discharge gap can be detected Oil level control, Fireproof control
  • Anti-carbon deposition function
  • Mirror surface processing
  • Hand control box

Digital control Discharge Generator:
  • AUTO processing function unit
  • Automatic positioning function unit
  • High speed and high precision machining system.
  • Automatic are cleaning circuit unit
  • Mirror processing circuit unit
  • Hard material (such as Tungsten, Titanium) processing circuit unit.
  • Fill the parameter in the process code easily
  • Data restore in case of power failure
  • Warning with error message if abnormal opation

Specifications:
Specification Unit FCNC-430 FCNC-540 FCNC-650 FCNC-850 FCNC-1060 FCNC-1260
Work Tank Internal Size mm 980x630x410 1370x720x450 1650x900x540 1650x1100x600 2000x1300x700 2000x1300x700
X, Y and Z Travel Size mm 400x300x300 500x400x300 600x400x350 800x500x400 1000x600x450 1200x600x450
Working Table Size mm 600x400 850x450 900x550 1000x600 1250x800 1250x800
Distance from Electrode Plate to work table mm 270-570 390-690 350-700 500-900 550-1000 550-1000
Max. Electrode Weight kg 50 150 150 200 300 300
Request
Callback
Yes! I am Interested

CNC Wire Abrasive Cut Machine

CNC Wire Abrasive Cut Machine
  • CNC Wire Abrasive Cut Machine
Get Best Quote
Approx. Price: Rs 9.67 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

Automatic GradeAutomatic
BrandFostex
Weight1000 kg
Control CabinetVertical
Power2.0 kVA
Abrasive Wire Dia0.35 mm
Movement for Hand Wheel Per Cycle1 mm
Pluse Equivalency0.001 mm
RoughnessRa 0.8-2.0
XY MotorStepper Motor
Control Cabinet Dimension750x680x1650 mm
SoftwareHL/HH/Autocut Software

It is Widely used for cutting graphite electrodes, epoxy plate, hard alloy, marble, jade, optical glass, ceramics, ferrite, semiconductor materials, carbonized silicon and other non conductive material.

Features:
  • Integrated programming and control software
  • Graphic tracking
  • Arbitrary angle rotation
  • Symmetric machining
  • Wire broken protection
  • Power failure protection
  • Automatic power off after finishing job.
  • USB port for inputting dxf drawing.
  • Forward and reverse processing
  • Analog Processing

Standard Accessories:
  • PC with Windows 7 / XP
  • Abrasive Wire
  • Pneumatic Wire Tighten Device
  • Ball Screw in X, Y Axis
  • Tool Box

Specifications:
ModelUnitFQT-2532FQT-3240
X Travelmm250320
Y Travelmm320400
Working Tablemm580x400710x470
Max. Load on Tablekg250300
Max. Cutting Thicknessmm250400
Abrasive Wire Diamm0.18-0.35
Movement for hand wheel per cyclemm11
Pluse Equivalencymm0.0010.001
RoughnessRaRa 0.8-2.0Ra 0.8-2.0
XY Motor-Stepper motorStepper motor
Max Cutting Speedmm/m/in100100
PowerKVA2.0 AC 415V/50 Hz, 3 Phase
WeightKg10001000
Machine Dimensionmm1450x1000x16001600x1250x1750
Control Cabinet Dimensionmm750x680x1650
Software
HL/HH/Autocut Software
Control Cabinet
Vertical
Request
Callback
Yes! I am Interested

CNC Wire Cut FZT Series Machine

CNC Wire Cut FZT Series Machine
  • CNC Wire Cut FZT Series Machine
  • CNC Wire Cut FZT Series Machine
Get Best Quote
Approx. Price: Rs 16.5 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

BrandFostex
Weight1500 kg
Automatic GradeAutomatic
Max Cutting Angle+/-3 deg/100 mm
Max Cut Thickness300 mm
Molybdenum Wire Dia0.22 mm
Power Supply415 V / 50 Hz,2.5 kW
Table Size700x500 mm
Table Travel400x320 mm
Wire Speed12,9,7,5,2 m/sec

Features:
  • Robust frame with ''C" mast.
  • Long travel rail installed in the bottom; Which improve the stability for heavy product.
  • With height adjustable diamond guider.
  • Four axes independent (vY/UN) work, with Taiwan linear and ball screw.
  • Special Tensioning mechanism for molybdenum wire, keep stable cutting.
  • Stepper motor is standard / Servo motor is optional.
  • Tolerance can keep in +1-0.006 mm, Roughness Ra 0.8
  • Full enclosed cover, Similar to European machine.
  • New generation control cabinet
  • High efficient

Specifications:
ModelFZT-320BJ/SFFZT-400BJ/SFFZT-500BJ/SFFZT-630BJ/SF
Table Size mm700x500820x6001000x7001200x800
Table Travel X/Y mm400x320500x400630x500800x630
Max Cut Thickness mm300300400400
Travel Size U/V mmNormal: 24x24 Large taper: D-60x60 E-130x130 T-240x240
Molybdenum Wire Dia mmMolybdenum wire 0.10-0.22
Wire Speed m/sec12,9,7,5,2
Max Cutting Angle+-3deg/80 mm
Process accuracy (mm)(Multi-cut): 10x10x30(Square)<=0.006; (one time out)<=0.012 (Multi-cut): (Octagon)<=0.009; (Straightness)<=0.006/50mm
Process roughness(Ra.um)(Multi-cut): Ra<=0.9 (Micro-pulsepower Ra<=0.8) (Singe-cut): Ra<=1.9
Driving motorStepper motor /AC servo motor*(Optional)
Guide screw and trackPrecision ball screw/Linear guide way
Tension Systemthree stage (0/1/2) tension adjustable
Power supply415V/50Hz, 2.5 Kw
Max. workpiece weight (kg)45060010001200
Weight (kg)1500170026003200
Dimension (mm)1750x1300x20001900x1450x20002050x1850x21002250x2050x2100
Request
Callback
Yes! I am Interested

CNC Wire Cut Machine FDK M Series

CNC Wire Cut Machine FDK M Series
  • CNC Wire Cut Machine FDK M Series
Get Best Quote
Approx. Price: Rs 8.5 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

Power SupplySingle phase, 220V/50Hz / Three phase, 415V/50Hz, 2.5 kW
Wire Speed12, 9, 7, 5, 2 m/sec
Max Cutting Angle+/-3 deg/80 mm (15, 30 and 60 deg is Optional)
Position Accuracy0.010/300 mm
Driving MotorStepper Motor / AC Servo Motor
Guide Screw and TrackPrecision Ball Screw / Linear Guide Way
Tension SystemSingle Stage Spring Tension Mechanical
Molybdenum Wire Dia0.30 mm

Features:
  • Robust frame with ''C" mast.
  • Four axes independent X/Y/U/V work
  • Taiwan LM guide in X and Y Axis
  • Taiwan Ball Screw in X and Y Axis

Standard Accessories:
  • High pressure coolant tank
  • DRO X and Y Axis
  • Ceramic nozzle
  • Auto lubrication pump
  • LM Guide for X and Y Axis
  • Steel Cover
  • Guide Wheel Pulley 5-Nos
  • Tool Box
  • Wire Tighten Pulley

Optional Accessories:
  • Guider Z axis
  • Diamond Nozzle
  • Taper Attachment for 15deg, 30deg and 60deg
  • Lifting Motor

Specifications:
ModelFDK7735-M+FDK7740-M+
Table Size mm440x620510x730
Table Travel X/Y mm320x400400x500
Max. Cut Thickness mm300300
Travel Size U/V mmNormal: 24x24 Large taper: D-60x60 E-130x130 T-240x240
Molybdenum Wire Dia mmMolybdenum wire 0.10-0.30
Wire Speed m/sec12,9,7,5,2
Max. Cutting Angle+-3deg/80 mm (15deg, 30deg and 60deg is optional)
Position Accuracy mm0.010/300
Process Roughness Ra.umMulti Cut: Ra less than 1.0 and Single Cut: Ra less than 2.0
Driving MotorStepper motor / AC servo motor
Guide Screw and TrackPrecision ball screw / Linear guide way
Tension SystemSingle stage Spring tensione Mechanical
Power SupplySingle phase, 220V/50Hz/Three phase, 415V/50Hz, 2.5 kW
Max. Workpiece Weight kg450600
Weight kg15001700
Dimension mm1700x1300x19001900x1450x1900
Request
Callback
Yes! I am Interested

CNC Bending Machine

CNC Bending Machine
  • CNC Bending Machine
Get Best Quote
Approx. Price: Rs 8 Lakh / UnitGet Latest Price

Product Details:

Usage/ApplicationIndustrial
Power2000 W
Voltage415 V
PhaseThree phase
BrandFostex
Weight80 ton
Automation GradeSemi-Automatic
Power SourceElectric
Country of OriginMade in India

Standard Feat.:
  • 5-axis machine with accurate two-axis back gauge & crowning
  • Designed to meet complicated & precise bending requirements
  • DNC 884 - Cybelec or DA 56 Delem press brake controller
  • USB port & CAN port for easy program & tool data storage & transfer
  • Ultrasonically tested IS 2062 grade robust Steel Structure
  • Servo hydraulics from BOSCH REXROTH Germany / ATOS Italy for
  • Y1-Y2 axis control
  • Linear press brake scale from HEIDENHAIN Germany or equivalent for
  • Y1 - Y2 axis position
  • Rigid upper beam guide on 8-point roller bearings
  • AC servo drive from Schneider or equivalent for X & R - axis control
  • Hydraulic crowning
  • Back gauge assembly included ball screw, AC servo drive, LM guides & timer belt
  • Multi "V" 4 way hardened & grounded die & punch from ROLLER! Italy or equivalent
  • Quick release clamps
  • Zero leak type PU seals
  • Front sliding sheet support with LM guide for easy movement
  • Multi-step back gauge fingers with a pair of LM Guides
  • Adaptability of various types of tools & special bending needs
Optional Feat.:
  • Higher version of windows & touchscreen controllers
  • Manual or automatic new standard premium crowning from WILA Netherlands or equivalent
  • Laser safety guard
  • Hydraulic tool clamping
  • Stress relieved structure
  • Special stroke and throat depth for deep bending
  • Special tools
  • European safety & CE markings
ModelTonnage in mtTable Length in mmBending Capacity in MS in mmClear Pass in mmRam Stroke in mmClear PassOpen Height in mmClose Height in mmThroat Depth in mmRam Speeds mm/secMotor HPOverall Dimension lxwxh in mm
FCPB-31530125x15002x15009001050100250150200100-7-8031700x1050x1900
FCPB-32040125x20002x20009001550100250150200100-7-8032200x1150x1900
FCPB-41540180x15003x15009001050100250150200100-7-8051700x1275x2300
FCPB-42040180x20002.5x20009001550100250150200100-7-8052200x1150x1900
Request
Callback
Yes! I am Interested

CNC Press Brake Machine

CNC Press Brake Machine
  • CNC Press Brake Machine
Get Best Quote
Approx. Price: Rs 15 Lakh / UnitGet Latest Price

Product Details:

Usage/ApplicationIndustrial
Capacity3000
Brand/MakeFostex
Automatic GradeSemi-Automatic
Bending MaterialMS + SS
Country of OriginMade in India
Voltage415 V
Frequency50 Hz
Weight78 ton

We are manufacturer and supplier of CNC Press Brake Machine. We design the given product following industrial standards by making use of best quality material and modern technology.

Request
Callback
Yes! I am Interested

CNC Wire Cutting Machine

CNC Wire Cutting Machine
  • CNC Wire Cutting Machine
  • CNC Wire Cutting Machine
  • CNC Wire Cutting Machine
Get Best Quote
Approx. Price: Rs 15.5 Lakh / UnitGet Latest Price
Product Brochure

Product Details:

Size/Dimension1700x1300x1900
Automatic GradeAutomatic
BrandFostex
Country of OriginMade in India
Wire Speed12 m/sec
Process Accuracy10x10x30 mm
Weight1500 kg
Voltage415 V
Frequency50 Hz

Request
Callback
Yes! I am Interested
X

Explore More Product

View All Product


Reach Us
Sunil Dubey (Partner)
Berlin Machine Corporation
Bhairavnath Industrial Estate, Gate No. 2/1, Plot No. 15, Near Choudhary Weighing Bridge, Dehu-Alandi Road, Chikhali, Near Paras Weighing Bridge
Pune - 411062, Maharashtra, India


Call Us


Send E-mail
